240W AC DC Adaptor 24V 10A POE Adapter for 3D printer Remote Control Airplane Electric Fireplace
XSG24010000

Power Adapter

Update

Product Electronics Parameter
Product name	240W AC DC Adaptor 24V 10A POE Adapter for 3D printer Remote Control Airplane Electric Fireplace
Model number	XSG24010000
AC input	Input Voltage range:	90～264Vac
	Reted input voltage:	100～240Vac
	InputFrequency Range:	47～62hz
	Input current max:	5.0A
	Inrush current:	140A Max/240V
	Efficiency:	90% min
	No load input power	<0.21W
	Leakage current:	<0.75mA/240V
DC output	Output voltage:	24V
	Output voltage tolerance:	5%
	Rated output current:	10.0A
	Output current:	0～10.0A
	Ripple and noise:	<300mVp-p
	CV or CC	Optional
	Current limited:	Optional
	LED indicator	Green color
Protection	Over current protection	PASS
	Over voltage protection
	Short circuit protection
	Over Temp protection
Environment	Operating Temp:	0℃～+45℃
	Storage Temp:	-30℃～+70℃
	Relative Humidity:	10%～90%
	Vibration and shock	Meet MIL-STD-810D
Safety	Safety standard	EN62368, EN60335, EN61558
	EMC/EMI	Meet FCC CLASS B,EN55032, EN55035
	EMS	EN61000－4－2
		EN61000－4－3
		EN61000－4－4
		EN61000－4－5
	A Harmonic source	Pass
	HI-pot: Primary to Secondary	3KVAC,5mA,60s
	Drop Test	As per UL regulation
	Burning test	100%,4-5 hours
Energy efficiency level		CEC level VI, Doe VI
Life	MTBF	50000 hours
Life	Warranty	2 years
Certificate	ETL, FCC, CE, UKCA, PSE

Model Name	Rated output voltage range (VDC)	Rated output current range (mA)	Max. output power (W)
XSECxxxyyyyzz, XSGxxxyyyyzz, XSExxxyyyyzz, XSECxxxyyyyyzz, XSGxxxyyyyyzz, XSExxxyyyyyzz, XSECxxxyyyy, XSGxxxyyyy, XSExxxyyyy, XSECxxxyyyyy, XSGxxxyyyyy, XSExxxyyyyy	12.0-16.8	10000-20000	292
	16.9-23.9	10000-18000	330
	24.0-38.0	9000-15000	378
	38.1-58.0	5500-9440	360
	58.1-88.0	4000-6200	360
